MaXpeedingrods Coilovers 24 Way Damper Kit compatible for MERCEDES S-CLASS W220 S430 S500 lowering kit

Introduction

Maxpeedingrods' street coilovers are designed and developed for all motoring enthusiasts that want excellent handling without sacrificing comfort. This suspension system is ideal for daily driving and occasional, light track use. High quality components are adopted to ensure product durability and stability. Each application is fully test fitted and completely road tested to guarantee all our customers perfect performance and comfort expectations.

Application

Compatible for Mercedes-Benz S-Class W220 2000-2006 With Airmatic Suspension without 4Matic
Compatible for Mercedes-Benz S Class S430 2000-2006
Compatible for Mercedes-Benz S Class S500 2000-2006

Reference OE/OEM Number: 2203205013,2203202438

(Not fit for models with ABC (Active Body Control) or 4MATIC (All Wheel Drive))


Specification

- Damping adjustable: Available, 24 ways damping force
- Height adjustable: Yes, lowering 1-3 inches depending on the vehicle models
- Top Mount: rubber structure
- Spring Rate Front: 10kg/mm(560lbs/in)
- Spring Rate Rear: 8kg/mm(448lbs/in)
- Front spring inner diameter: 70.5mm
- Rear spring inner diameter: 70.5mm
- Spring length Front: 230mm
- Spring length Rear: 230mm
- Spring Preload advised: 7-10 mm
- Color: Red body with black spring

Package included

1 x Set of Coilover Spring Kit (2 Front + 2 Rear)
1 x Pair of wrenches for height adjustment

Features

1. Lowered height adjustment from 1" - 3" which allow lower center of gravity and also add a more aggressive stance
2. Adjustable pre-load spring tension to reduce the shaking motion to a certain extent
3. High Viscosity Index damper oil---make damping more stable and smooth in wide temperature range.
4. 24 Clicks of Rebound Adjustments -- This allows you the ability to perfectly dial in your coilovers system. For a nice comfortable driving, set damping to full soft. For more spirited driving, set it to 16 clicks. For occasional track days, set it to full stiff.
5. CNC machined Aluminum top mounts and lockers-- - excellent strength, and save weight
6. High Rigidity 55CrSi Steel Cold-bent Coil Springs --- more than 600,000 times continuously test to assure it's high tensile strength.
7. All inserts come with fitted long rubber boots--- To protect the damper more well and be durable.
9. Advanced Twin-Tube Technology ---provides excellent handling & control characteristics for most driving conditions
10. Anodized Shock Body With Anti-Corrosion Coating- Anodized Aluminum And Powder Coated Carbon Steel Parts

Note

1. All modifications must be installed by licensed mechanics and in compliance with your local modification regulations.
2. Please ensure all components are tightened with correct torque specifications (which can be found in the vehicle service manual)before and after installation. Any loose nuts, bolts, or locks will cause noise. Do check and tighten before serious problems happen.
3. Impact wrench is prohibited during the installation, it will loosen or damage the product.
4. Examine the clearance between tires and suspension. ( The minimum clearance should be 4mm, otherwise, you need to add wheel spacers. Caution: It is not sufficient with torsion beam trailing arm axles)
5. We suggest regular maintenance for the coil-over, spray with some WD40 every 3-4 months will keep it smooth and clean, which helps to extend the lifetime.
